8 PORT IP BASED KVM SWITCH

IP BASED KVM SWITCH

Model No : PA-HT1108

Weight In KG :2.9

Weight In LB :6.39340



Request for Price
  • Description
  • Sepcification
  • Download
  • Buy

OVERVIEW

The PA-HT1108 rack mount KVM over IP Switch is a control unit that allows secure access to 8 computers from a single KVM console.

The PA-HT1108 IP KVM features IP-based connectivity that allows local and remote operators to monitor and access the computers. With TCP/IP communications protocol, the PA-HT1108 IP KVM can be accessed from any computer on the LAN, WAN or Internet.

It’s easy to set up the PA-HT1108 IP KVM, just plug the cable into the appropriate port, no software needed, no complicated installation procedures, and no compatibility issues. Connect computers with compact RJ-45 connectors and Cat 5e/6 cable, transmitting distance is up to 100m.


FEATURES

HARDWARE FEATURES

      • Rack-mountable in 1U system rack
      • Dual power supply

LOCAL CONSOLE

      • Control up to 8 computers
      • Support 1 local user and 1 remote user, port share mode allows local and remote users to gain access to a server simultaneously
      • Easy-to-use switching by browser-based UI interface, hotkeys and pushbuttons
      • Support servers with VGA/DVI/HDMI/DP port
      • Multiplatform client support (Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
      • Local Console, Browser, and AP GUIs offer a unified Multilanguage interface
      • Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
      • Video synchronization with local console - EDID information for local console display can be stored in the host module for video resolution optimization
      • Keyboard and mouse emulation to ensure the normal booting
      • Broadcast mode--operations simultaneously performed on all selected computers
      • Auto scan feature for monitoring user-selected computer
      • Hot pluggable--add or remove computers without having to power down the switch

REMOTE CONSOLE

      • Adaptive 10 / 100 / 1000 Mbps network
      • WEB browser-based or KVM Clients remote management BIOS-level access
      • BIOS-level access
      • Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 60 FPS
      • Full screen or scalable video display
      • Remote users and local users can control the same server/computer synchronously
      • Support AES / DES / 3DES encryption
      • Support audit function-allows the administrator to audit the device through the system log and operation log
      • Exit Macros support
      • Configurable user and group permissions for server access and control
      • Support strong password
      • Support firmware upgrade


SPECIFICATIONS

COMPUTER CONNECTIONS

Computer Connection8
Port selection8
Connector
Console

Keyboard , Mouse : 2x USB TYPE A

Monitor : 1-HDB-15 Female(blue)

KVM Port (RJ-45)
8
Upgrading switch
1x RJ11 Female
Power
3-Prong AC socket
Switch

Port Selection
8
Reset
1x touch-button
Upgrading switch
1x toggle switch
Power
1x rocker switch
LEDs

Online (Green)
8
Selected (Orange)
8
Power
1(blue)
Cascade display
2x 7- Segment (orange)
Remote

Remote control
KVM control (ActiveX control)
Management way
Web
Security
DES encryption
Resolution
1920×1080@60Hz
I/R Value
100V-240Vac, 50-60Hz, <1.5A
PORT SELECTION
pushbuttons, hotkeys, OSD menu
Power Consumption
8W

Environment Requirements


OPERATING TEMPERATURE
0—50 ℃
STORE TEMPERATURE
-20—60 ℃
HUMIDITY
0—80% RH, non-condensing

Physical Features


NET WEIGHT
2.9kg
PRODUCT DIMENSION (W × D × H)
433X171X44.5mm
